Lasersix Rapido Trauma is a 1064nm diode laser dedicated to physiotherapy and rehabilitation procedures.

The 1064nm wavelength penetrates deeply into tissues, triggering several biochemical reactions that reduce pain.
Equipped with the Directo handpiece, which prevents energy dispersion, it ensures effective treatments and quicker results.
Suitable for upper, medium, and lower body treatments.

Specifications:

• Collimated tip
• Treatments for all skin types
• Portable battery-powered
• Wireless foot pedal
• 6 selectable languages: Italian, English, Spanish, French, German, Portuguese.

• Certificate: CE 0476
• Channel: physiotherapy, sports clubs

• Wavelength:     1064nm
• Power: 10w
• Diode:  Gallium-Aluminum-Arsenide (GaAlAs)
• Frequency: Up to 25 kHz
• Pulse mode:
  • CW (Continuous wave) –
  • SP (super pulse)  – pulsed wave is 20µs up to 1s
• Medical Laser: class IIB / 4
• Dimensions: 205x130x50mm
• Weight: 1.5 KG
• Validity period: 5 years
• External connections: Interlock + footswitch
• IP protection level: IPX0 (Pedal IPX1)
• Isolation class and part applied:  II – tipo BF
• Cooling system: air
• Max absorption of the system:                4.5A
• Input of power supply*: 100 – 240 VAC
• Maximum current absorbed by the network: 1.3A AC
• Supply voltage for the system: 19VDC
• Connector: SMA 905
• Length: 2 – 3 m
• Divergence of output aiming beam (N.A.): 14° (0.22)
• Spot size at target: 1 cm²
• Energy density: 1 W/cm²  x sec (collimated laser)
• Pulse Repetition Rate: 20 kHz
• Pulse Energy:    20 µs
• Pulse Width:     20μs up to 1s
• Average output power/energy                Max:  10 watts CW
• NOHD: 4.77 mt
• Wavelength of aiming beam: 635±10 nm /650±10nm depending on the model
• Aiming beam power: <5mW
• Laser shutter: Footswitch command
• Adjustment of duration of emission: from 1 to 180 seconds
• Stability of emission power**:               ± 20%
• Procedural use :
  • TEMPERATURE: 10 – 30 °
  • HUMIDITY: 30 – 70%
  • ATMOSPHERIC PRESSURE: 70/160 kPa
• Storage conditions
  • TEMPERATURE: 5 – 50 °C
  • HUMIDITY: 30 – 70%
  • ATMOSPHERIC PRESSURE. 50/160 kPa

*Protection against anaesthetics: This device is not suitable for use with a mixture of inflammable anaesthetics with air oxygen or nitrogen dioxide.
